550W/750W/1100W/1.5KW/2.2KW AC Servo Motor Driver Speed Control Kit 1.85-6.85Nm

【USA Stock & Located in USA & fast shipping】550W/750W/1100W/1.5KW/2.2KW AC Servo Motor Driver Speed Control Kit 1.85-6.85NmShip from USA Warehouse fast shipping service to US CustomersPlease note that the current model of this product available in our US warehouse does not support RS232/RS485 communication functions.Package include:1 x 110V AC Brushless servo motor (550W /750W /1100W/1500W / 2200W are optional)1 x speed controller1 x Pdf user manualFeauresPure Copper MotorMetal GearStrong powerEfficient heat dissipationInfinitely adjustable speedSelf-locking switchDust shieldMulti-angle grindingWear-resistant and durableSupport one-key forward and reverse rotation, support soft start (both start and stop ease).The motor output shaft has 15mm thread, which can be equipped with synchronous pulley and ER special chuck, which is widely used in belt sander, polishing machine, small lathe, milling machine, etc.Pure copper motor, strong power and efficient heat dissipation.Strong anti-interference ability, low noise, with multiple protections such as overcurrent, overload and overvoltage.Product weight (including packaging):550W kit: 2.8kg/6.2 lb750W kit: 3.1kg/6.8 lb1100W kit: 3.8kg/8.3 lb1500W kit: 4.7kg/ 10.3 lb2200W kit: 5.2kg/ 11.4 lbAluminum headAdopting high quality aluminum head, not easy to crack under high intensity working condition.All-copper motor & Thickened protective coverHigh temperature resistance, good conductivity, long service life.Strong power, 6000 rotational speed, can last more than 72 hours of work time.Prevent sparks and dust from flying, and prevent the cutting piece from breaking and getting hurt.Cooling air outlet360° grille air outlet design, strong heat dissipation, delayed service life.Please note:The motor shaft defaults to sending a "threaded shaft" Parameters:1. Rated power: 550W/750W/1100W/1500W/2200W2. Rated voltage: AC 110V 3. Speed range (RPM): 200-7000 (550W); 200-6500 (750W); 200-6000 (1100W); 200-5000 (1500W)；200-4500 (2200W)4. Rated torque (Nm): 1.85 (550W); 2.62 (750W); 3.55 (1100W); 5.02 (1500W)); 6.85 (2200W)5. Installation size: 69mm6. Shaft diameter: 15mm7. Out shaft length: 27+15mm8. Mounting thread: M6 through hole9. Key slot: 5*5*20mmFeatures:1. Support one-key forward and reverse rotation, support soft start (both start and stop ease).2. The motor output shaft has 15mm thread, which can be equipped with synchronous pulley and ER special chuck, which is widely used in belt sander, polishing machine, small lathe, milling machine, etc.3. Pure copper motor, strong power and efficient heat dissipation.4. Strong anti-interference ability, low noise, with multiple protections such as overcurrent, overload and overvoltage.Power range:550WModel: Brushless Servo Motor Control SystemMotor torque: ≦1.85N.MVoltage range: 110VACMotor pole pairs: 8 pairsInput frequency: 50-60hzMotor category: permanent magnet brushless servo motorInsulation class: F classSpeed range: 200-7000 rpmControl method: turn on the power, adjust the speed with the knobProtection mode: overcurrent, overvoltage, short circuit protection, locked rotor protectionPower range:750WModel: Brushless Servo Motor Control SystemMotor torque: ≦2.62N.MVoltage range: 110VACMotor pole pairs: 8 pairsInput frequency: 50-60hzMotor category: permanent magnet brushless servo motorInsulation class: F classSpeed range: 200-6500 rpmControl method: turn on the power, adjust the speed with the knobProtection mode: overcurrent, overvoltage, short circuit protection, locked rotor protectionPower range:1100WModel: Brushless Servo Motor Control SystemMotor torque: ≦3.55N.MVoltage range: 110VACMotor pole pairs: 8 pairsInput frequency: 50-60hzMotor category: permanent magnet brushless servo motorInsulation class: F classSpeed range: 200-5500 rpmControl method: turn on the power, adjust the speed with the knobProtection mode: overcurrent, overvoltage, short circuit protection, locked rotor protectionPower range: 1500WModel: Brushless Servo Motor Control SystemMotor torque: ≦5.02N.MVoltage range: 110VACMotor pole pairs: 8 pairsInput frequency: 50-60hzMotor category: permanent magnet brushless servo motorInsulation class: F classSpeed range: 200-5000 rpmControl method: turn on the power, adjust the speed with the knobProtection mode: overcurrent, overvoltage, short circuit protection, locked rotor protectionPower range: 2200WModel: Brushless Servo Motor Control SystemMotor torque: ≦6.85N.MVoltage range: 110VACMotor pole pairs: 8 pairsInput frequency: 50-60hzMotor category: permanent magnet brushless servo motorInsulation class: F classSpeed range: 200-4500 rpmControl method: turn on the power, adjust the speed with the knobProtection mode: overcurrent, overvoltage, short circuit protection, locked rotor protection Purpose of each button:F : Enter parameter combination key; combined with other keys to enter parameter setting mode, error recovery keyD: Direction switching; the main function is to switch directions and confirm parameter settings+ : Increase motor speed; adding keys to parameter and index values- : Reduce motor speed; parameter and index value decrease keyAdjustment method for technician mode parameters:a) Press and hold the "F" key while pressing the "+" key, and the screen will display as P-00;b) Press the "+" or "-" keys to adjust the parameter number;c) Press the "F" key to enter the parameters, and the screen will display the parameter values;d) Press the "+" or "-" keys to adjust to the desired parameter value;e) Press the "D" key to save the parameters and exit.Restore factory settings:While holding down the "F" key, press the "+" key once, and the screen will display as P-00. Then, hold down the "D" key for 3 seconds and release it.Error code（Fault handling）Er03: Motor Hall or phase line errorPoor plug contact;The motor is not installed properly;Hall is broken.Er04: Locked rotor protectionMotor overload;The four core wires connected to the motor and electronic control have poor contact.Er05: Hardware overcurrent protectionMotor overload;The signal line has poor contact or is broken.Er07: Serial communication timeout errorThe connection wire between the display screen and the motherboard is poor or the motherboard is damaged. Application areas: Industrial manipulator，Semiconductor equipmentCarving equipment，Measuring equipment，Medical equipment，robot and otherautomated equipment on the market.Suitable for the following occasionsRepetitivepositioning control occasions; occasions with many input and outputpoints demand; networking communication applications.Shipping Please open the package and check if there are some damages before sign,if there are some damages,please do not sign and contact us immediately. Problem&Feedback Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. Pls contact us before you want to leave any negative feedback. Refund Any reason required for all refund. Item must be in it's original condition and no physical damage,buyer responsible for all shipping cost. When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos.
